Item Parameter

C3

Unit

Rated load (Emax):

10,20,30,40,50

t

Maximal numbers of load cell verification Intervals (Nlc):

2000

d

Minimum load cell verification intervals Intervals

( Vmin):

0.02

% of rated load

Rated output (Cn):

2.0±0.1%

mV/V

Combined error:

0.027

-% of rated output

Temperature effect on sensitivity(Tkc):

0.0024

=% of rated output/

Temperature effect on zero balance(Tk0):

0.002

-% of rated output

Zero balance:

1.0

-% of rated output

Input resistance(Rlc):

775±5

Ω(Ohms)

Output resistance(Ro):

702±2

Ω(Ohms)

Insulation resistance:

≥5000

MΩ (Mega-Ohms)

Safe overload:

150

% of rated capability

Ultimate overload:

300

% of rated capability

Operating temperature range:

-20~+160/-5~+320

℃/ °F

Recommend excitation:

8~15

V( DC or AC)

Maximum excitation:

24

V( DC or AC)

Material of elastomer:

Alloy steel / Stainless steel

Protection class:

IP67/IP68
